| Type |
Grooved drum type |
| Number of drum |
40/60/80/100/120(standard.100s) |
| Drum gauge(mm) |
254 |
| Yam traverse(mm) |
152 |
| Winding speed (m/min) |
510/575/643/713 |
| Sixe of full package(mm) |
Base φ 200×152 |
| Drum |
φ82mm2 2/1 turms |
| End-breakage automatic stop motion |
lndividual spindle control |
| Cone size |
3°30''''/5°57/9°15''''paper bobbin(or6°wooden bobbin) |
| Ribbon breaking device |
Non-contact intermittent Swith device |
| Form of supply |
To suit spinning cops or thread bobins of twisting frame |
| Cleaning device |
Model GU013 cleaning blower |
| Operatue carriage |
Model GU012 operative carriage |
| Yam clearer |
Electrenic clrarer with multi-functions |
| Bobbin holder |
Single-arm holding type |
| Drive:main motor |
2 pcs.1.8kw 1440r/min |
| Pilot motor |
1 pcs.0.37kw 960r/min |
