Introduction£º
¡ñUnique construction commutation,the high efficiency heat exchanger and DBNP pump are combined integrative,they are designed without external circulation pipes, saving space 25%.
¡ñSpecial compact designed calandria heat exchanger is installed outside, in same heat exchanging condition, it can achieve the best exchange effect of heating and cooling.
¡ñMain pump are controlled by stepless flowing rate of inverter, it can achieve the same dyeing effect according to different dyeing techniques, and save power consumption when starting and de-loading.
|
|
¡ñSpecial steady commutation mechanism allows liquid flow to change direction without stopping main pump, thus increasing liquor circulating times to improve level-dyeing property.
¡ñWith multi-function intelligent computer, it simplified the water inletting, draining, eternal flowing, internal flowing, and etc.operation.
¡ñPressure dewatering to decrease the water containing in package yarn.
¡ñDyeing with Iow liquor ratio of 1:6 can save dyestuffs, chemicals,steam and water thus decreasing the drainage.
¡ñThe high efficiency heat exchange between the liquid stream and dyeing liquor improve the speed of dyeing technique process,shorten the time.
¡ñRapid loading creel, easy to take out the package, thereby reducing the labor intensity and saving the working efficiency. |
| Technical parameter£º |
¡ñMax. working pressure: 0.4Mpa.
¡ñMax. working temperature: 140¡æ
¡ñHeating rate: 20~130¡æ about 30 minutes (Saturated steam pressure 0.7Mpa)
¡ñCooling rate: 130-80¡æ about 20 minutes (cooling water pressure 0.3Mpa)
¡ñStandard spindle dia. is ¡Ó48mm, the ¡Ó29mm triangle spindle is only for 6 layers package or below.
¡ñStandard package size is ¡Ó165mmxh160mm, the max. capacity is calculated according to that every package is 1 kg. |
|
Specification£º |
Model |
NO.of Layers |
NO.of Packages |
Max Capacity£¨Kg£© |
Lifting height(mm) |
Main pump power£¨Kw£© |
DF241C-43 |
6 |
24 |
24 |
3850 |
5.5 |
| DF241C-53 |
36 |
36 |
4020 |
7.5 |
| DF241C-70 |
54 |
54 |
4370 |
11 |
| DF241C-85 |
108 |
108 |
4550 |
15 |
| DF241C-90 |
114 |
114 |
4600 |
15 |
| DF241C-105 |
144 |
144 |
|
18.5 |
| DF241C-120 |
216 |
216 |
|
22 |
| DF241C-43 |
8 |
32 |
32 |
|
7.5 |
| DF241C-53 |
48 |
48 |
4740 |
11 |
| DF241C-70 |
9 |
81 |
81 |
5250 |
15 |
| DF241C-85 |
162 |
162 |
5440 |
18.5 |
| DF241C-90 |
171 |
171 |
5460 |
18.5 |
| DF241C-105 |
216 |
216 |
5570 |
22 |
| DF241C-120 |
324 |
324 |
5720 |
30 |
| DF241C-145 |
486 |
486 |
6050 |
45 |
| DF241C-166 |
621 |
621 |
6210 |
55 |
| DF241C-186 |
810 |
810 |
|
75 |
| DF241C-85 |
12 |
216 |
216 |
|
22 |
| DF241C-90 |
228 |
228 |
|
22 |
| DF241C-105 |
288 |
228 |
6670 |
30 |
| DF241C-120 |
432 |
432 |
6820 |
37 |
| DF241C-145 |
648 |
648 |
7020 |
55 |
| DF241C-166 |
828 |
828 |
7500 |
75 |
| DF241C-186 |
1080 |
1080 |
7650 |
90 |
| DF241C-200 |
1296 |
1296 |
7700 |
110 |
| DF241C-220 |
1500 |
1500 |
|
132 |
| DF241C-226 |
15 |
2010 |
2010 |
9000 |
185 |
|
| Note: Specifications of the above machines are Only for reference,The comapny reserves the right of amendment. |
|
